Name: MOS Ceramic Plate CD Ozone Generator
Brand: ONYX
Author: ONYX Technical Team

Advantages

Parameter

Product Series	ONYX-MOS-W
Ozone production	30-100g/h
Ozone concentration	390mg/L
Oxygen inlet pressure	1.2-3.5Bar
Intake requirements	Oxygen-rich source, oxygen content>93%, dew point -55~-60℃
Working environment	cooling water ≤ 20℃, temperature ≤ 25℃, humidity < 85%RH
Power	185V-265V，50/60HZ

Technical Specifications

Parameter	Specification
Model	MOS Ceramic Plate CD Ozone Generator
Treatment Capacity	Customized, range 1 - 100,000 m3/day
Reactor Material	316L Stainless Steel / 304 Stainless Steel
Operating Temperature	5 - 45 °C
IP Rating	IP68 (lamp module) / IP65 (control cabinet)
Cleaning Method	Automatic mechanical cleaning / Chemical cleaning (optional)
Control System	PLC automatic control, SCADA remote monitoring supported
Certification	CE, NSF/ANSI 55, GB/T 19837

Application Scenarios

MOS Ceramic Plate CD Ozone Generator is widely used in the following applications:

Municipal Water & Wastewater: Drinking water plant disinfection, wastewater effluent treatment, water reuse disinfection
Industrial Water Treatment: Electronics ultrapure water, pharmaceutical water, food and beverage processing water
Marine & Shipping: Ballast water treatment, onboard sewage treatment
Aquaculture: Recirculating aquaculture system (RAS) water disinfection, hatchery water treatment
Swimming Pools & Landscapes: Pool water disinfection, ornamental water circulation
Advanced Oxidation: UV-AOP process for degrading refractory organics and removing micropollutants

Technical Principle

UV disinfection technology utilizes ultraviolet light (wavelength 254nm) to damage the DNA/RNA structure of microorganisms, rendering them unable to reproduce and effectively sterilizing the water. Compared with chemical disinfection, UV treatment requires no chemical additives, produces no disinfection by-products (DBPs), achieves high inactivation efficiency against bacteria, viruses, and spores, and requires only seconds of contact time. It is a safe, environmentally friendly physical disinfection method.

ONYX UV equipment features optimized reactor hydraulic design ensuring uniform UV dose distribution, paired with an automatic cleaning system to maintain lamp transmittance for long-term stable operation. The equipment supports online UV dose monitoring and real-time operational status feedback, and can be seamlessly integrated into existing SCADA systems.
